Acronym stut xethi
Name small tritrigonal hexacositrishecatonicosachoron
Circumradius sqrt[8+3 sqrt(5)] = 3.835128
Colonel of regiment stut phiddix
Face vector 2400, 10800, 7680, 960
Confer
general polytopal classes:
Wythoffian polychora
External
links
hedrondude   polytopewiki   WikiChoron

As abstract polytope stut xethi is isomorphic to getit xethi, thereby replacing the decagons by decagrams and the pentagons by pentagrams, resp. replacing the gidtid by sidtid, saddid by gaddid, and tid by quit gissid. – As such stut xethi is a lieutenant.


Incidence matrix according to Dynkin symbol

o3o3x5x3*a5/4*c

. . . .         | 2400 |    6    3 |    3    3    3    6 |   1   1   3   3
----------------+------+-----------+---------------------+----------------
. . x .         |    2 | 7200    * |    1    0    1    1 |   1   0   1   1
. . . x         |    2 |    * 3600 |    0    2    0    2 |   0   1   2   1
----------------+------+-----------+---------------------+----------------
o . x . *a5/4*c |    5 |    5    0 | 1440    *    *    * |   1   0   1   0
o . . x3*a      |    3 |    0    3 |    * 2400    *    * |   0   1   1   0
. o3x .         |    3 |    3    0 |    *    * 2400    * |   1   0   0   1
. . x5x         |   10 |    5    5 |    *    *    * 1440 |   0   0   1   1
----------------+------+-----------+---------------------+----------------
o3o3x . *a5/4*c    20 |   60    0 |   12    0   20    0 | 120   *   *   *
o3o . x3*a          4 |    0    6 |    0    4    0    0 |   * 600   *   *
o . x5x3*a5/4*c    60 |   60   60 |   12   20    0   12 |   *   * 120   *
. o3x5x            60 |   60   30 |    0    0   20   12 |   *   *   * 120

o3o3/2x5x3/2*a5*c

. .   . .         | 2400 |    6    3 |    3    3    3    6 |   1   1   3   3
------------------+------+-----------+---------------------+----------------
. .   x .         |    2 | 7200    * |    1    0    1    1 |   1   0   1   1
. .   . x         |    2 |    * 3600 |    0    2    0    2 |   0   1   2   1
------------------+------+-----------+---------------------+----------------
o .   x .   *a5*c |    5 |    5    0 | 1440    *    *    * |   1   0   1   0
o .   . x3/2*a    |    3 |    0    3 |    * 2400    *    * |   0   1   1   0
. o3/2x .         |    3 |    3    0 |    *    * 2400    * |   1   0   0   1
. .   x5x         |   10 |    5    5 |    *    *    * 1440 |   0   0   1   1
------------------+------+-----------+---------------------+----------------
o3o3/2x .   *a5*c    20 |   60    0 |   12    0   20    0 | 120   *   *   *
o3o   . x3/2*a        4 |    0    6 |    0    4    0    0 |   * 600   *   *
o .   x5x3/2*a5*c    60 |   60   60 |   12   20    0   12 |   *   * 120   *
. o3/2x5x            60 |   60   30 |    0    0   20   12 |   *   *   * 120

o3/2o3x5x3/2*a5*c

.   . . .         | 2400 |    6    3 |    3    3    3    6 |   1   1   3   3
------------------+------+-----------+---------------------+----------------
.   . x .         |    2 | 7200    * |    1    0    1    1 |   1   0   1   1
.   . . x         |    2 |    * 3600 |    0    2    0    2 |   0   1   2   1
------------------+------+-----------+---------------------+----------------
o   . x .   *a5*c |    5 |    5    0 | 1440    *    *    * |   1   0   1   0
o   . . x3/2*a    |    3 |    0    3 |    * 2400    *    * |   0   1   1   0
.   o3x .         |    3 |    3    0 |    *    * 2400    * |   1   0   0   1
.   . x5x         |   10 |    5    5 |    *    *    * 1440 |   0   0   1   1
------------------+------+-----------+---------------------+----------------
o3/2o3x .   *a5*c    20 |   60    0 |   12    0   20    0 | 120   *   *   *
o3/2o . x3/2*a        4 |    0    6 |    0    4    0    0 |   * 600   *   *
o   . x5x3/2*a5*c    60 |   60   60 |   12   20    0   12 |   *   * 120   *
.   o3x5x            60 |   60   30 |    0    0   20   12 |   *   *   * 120

o3/2o3/2x5x3*a5/4*c

.   .   . .         | 2400 |    6    3 |    3    3    3    6 |   1   1   3   3
--------------------+------+-----------+---------------------+----------------
.   .   x .         |    2 | 7200    * |    1    0    1    1 |   1   0   1   1
.   .   . x         |    2 |    * 3600 |    0    2    0    2 |   0   1   2   1
--------------------+------+-----------+---------------------+----------------
o   .   x . *a5/4*c |    5 |    5    0 | 1440    *    *    * |   1   0   1   0
o   .   . x3*a      |    3 |    0    3 |    * 2400    *    * |   0   1   1   0
.   o3/2x .         |    3 |    3    0 |    *    * 2400    * |   1   0   0   1
.   .   x5x         |   10 |    5    5 |    *    *    * 1440 |   0   0   1   1
--------------------+------+-----------+---------------------+----------------
o3/2o3/2x . *a5/4*c    20 |   60    0 |   12    0   20    0 | 120   *   *   *
o3/2o   . x3*a          4 |    0    6 |    0    4    0    0 |   * 600   *   *
o   .   x5x3*a5/4*c    60 |   60   60 |   12   20    0   12 |   *   * 120   *
.   o3/2x5x            60 |   60   30 |    0    0   20   12 |   *   *   * 120
