Acronym thawrorh
Name thawro rhombochoron


 ©
the mibdi-trip rings:

the peppy pairs:
 ©
Circumradius ...
Lace city
in approx. ASCII-art
                   x3o

            f3x           f3x
       o3F                     o3F
                   x3F
x3x                                  x3x
                   F3x
       F3o                     F3o      		(F=ff=x+f)
            x3f           x3f

                   o3x
General of army (is itself convex)
Colonel of regiment (is itself locally convex)
Confer
related CRFs:
tewau thawrorh
External
links
quickfur

Essentially, for making this structure convex, are these pyramid pairs: In fact it is the part of the lace city, which is Fo3oF&#f, which would feature f-edges, if those wheren't contained within these pentagons. This too requires is what requires the symbols x3F and F3x in the lace city, as those would be the positions of the pentagon vertices opposite to their head vertex at the x3x position. – It might be possible to blend at these pyramid pairs a line || perp {5} each. Then it not even would be required to surmount the opposite positions by x3F and F3x, but one might remain with those subsymbols of ex, i.e. with o3f and f3o instead. The left half, say, of the lace city then would lead directly to dim. thawro-wedged 1/6-luna of ex. But unfortunately that one would not be convex any more, as its hull would feature right those above mentioned f-edges.

A different way to capture these f-edges by different pentagons would be featured in thawro-wedged 2/6-luna of ex, which thus becomes a CRF again.


Incidence matrix

12  *  * *  * |  2  2  2  0  0  0  0  0  0  0  0 0 0 0 | 1  2  2  1  2  2  0  0  0  0  0 0  0  0  0  0  0  0 0 | 2  2  2 0  0 0 0  0  at x3x (of l.c.) ones
 * 12  * *  * |  0  2  0  2  2  2  0  0  0  0  0 0 0 0 | 0  1  0  2  2  2  1  1  2  2  1 0  0  0  0  0  0  0 0 | 1  1  4 1  1 0 0  0  at o3F (of l.c.) ones
 *  * 24 *  * |  0  0  1  1  1  0  1  1  1  1  1 0 0 0 | 0  0  1  0  1  1  1  1  1  1  0 1  1  1  1  1  1  1 0 | 1  1  1 1  1 1 1  1  at f3x (of l.c.) ones
 *  *  * 6  * |  0  0  0  0  0  0  0  0  4  0  0 2 0 0 | 0  0  0  0  0  0  4  0  0  0  0 0  2  2  0  0  0  0 1 | 2  0  0 2  0 1 0  0  at x3o (of l.c.) ones
 *  *  * * 12 |  0  0  0  0  0  2  0  0  0  2  2 0 1 1 | 0  0  0  2  0  0  0  0  2  2  2 0  0  0  1  1  2  4 0 | 0  0  4 1  2 0 1  2  at x3F (of l.c.) ones
--------------+----------------------------------------+-------------------------------------------------------+--------------------
 2  0  0 0  0 | 12  *  *  *  *  *  *  *  *  *  * * * * | 1  1  1  0  0  0  0  0  0  0  0 0  0  0  0  0  0  0 0 | 2  1  0 0  0 0 0  0
 1  1  0 0  0 |  * 24  *  *  *  *  *  *  *  *  * * * * | 0  1  0  1  1  1  0  0  0  0  0 0  0  0  0  0  0  0 0 | 1  1  2 0  0 0 0  0
 1  0  1 0  0 |  *  * 24  *  *  *  *  *  *  *  * * * * | 0  0  1  0  1  1  0  0  0  0  0 0  0  0  0  0  0  0 0 | 1  1  1 0  0 0 0  0
 0  1  1 0  0 |  *  *  * 24  *  *  *  *  *  *  * * * * | 0  0  0  0  1  0  1  0  0  1  0 0  0  0  0  0  0  0 0 | 1  0  1 1  0 0 0  0  at single thawro
 0  1  1 0  0 |  *  *  *  * 24  *  *  *  *  *  * * * * | 0  0  0  0  0  1  0  1  1  0  0 0  0  0  0  0  0  0 0 | 0  1  1 0  1 0 0  0  between neighbouring thawros
 0  1  0 0  1 |  *  *  *  *  * 24  *  *  *  *  * * * * | 0  0  0  1  0  0  0  0  1  1  1 0  0  0  0  0  0  0 0 | 0  0  2 1  1 0 0  0
 0  0  2 0  0 |  *  *  *  *  *  * 12  *  *  *  * * * * | 0  0  1  0  0  0  0  1  0  0  0 1  1  0  0  0  1  0 0 | 1  1  0 0  1 1 1  0  at single thawro
 0  0  2 0  0 |  *  *  *  *  *  *  * 12  *  *  * * * * | 0  0  0  0  0  0  0  0  0  0  0 1  0  1  1  1  0  0 0 | 0  0  0 1  0 1 1  1  between neighbouring thawros
 0  0  1 1  0 |  *  *  *  *  *  *  *  * 24  *  * * * * | 0  0  0  0  0  0  1  0  0  0  0 0  1  1  0  0  0  0 0 | 1  0  0 1  0 1 0  0
 0  0  1 0  1 |  *  *  *  *  *  *  *  *  * 24  * * * * | 0  0  0  0  0  0  0  0  1  0  0 0  0  0  1  0  1  1 0 | 0  0  1 0  1 0 1  1  peppy-squippy-trip-tet
 0  0  1 0  1 |  *  *  *  *  *  *  *  *  *  * 24 * * * | 0  0  0  0  0  0  0  0  0  1  0 0  0  0  0  1  0  1 0 | 0  0  1 1  0 0 0  1  peppy-mibdi-tet
 0  0  0 2  0 |  *  *  *  *  *  *  *  *  *  *  * 6 * * | 0  0  0  0  0  0  2  0  0  0  0 0  0  0  0  0  0  0 1 | 2  0  0 1  0 0 0  0
 0  0  0 0  2 |  *  *  *  *  *  *  *  *  *  *  * * 6 * | 0  0  0  2  0  0  0  0  0  0  0 0  0  0  0  0  0  4 0 | 0  0  4 0  0 0 0  2  at peppies
 0  0  0 0  2 |  *  *  *  *  *  *  *  *  *  *  * * * 6 | 0  0  0  0  0  0  0  0  0  0  2 0  0  0  0  0  2  0 0 | 0  0  0 1  2 0 1  0  at mibdies resp. trips
--------------+----------------------------------------+-------------------------------------------------------+--------------------
 6  0  0 0  0 |  6  0  0  0  0  0  0  0  0  0  0 0 0 0 | 2  *  *  *  *  *  *  *  *  *  * *  *  *  *  *  *  * * | 2  0  0 0  0 0 0  0  {6}
 2  1  0 0  0 |  1  2  0  0  0  0  0  0  0  0  0 0 0 0 | * 12  *  *  *  *  *  *  *  *  * *  *  *  *  *  *  * * | 1  1  0 0  0 0 0  0  {3} thawro S-polar
 2  0  2 0  0 |  1  0  2  0  0  0  1  0  0  0  0 0 0 0 | *  * 12  *  *  *  *  *  *  *  * *  *  *  *  *  *  * * | 1  1  0 0  0 0 0  0  {4} thawro S-tropal
 1  2  0 0  2 |  0  2  0  0  0  2  0  0  0  0  0 0 1 0 | *  *  * 12  *  *  *  *  *  *  * *  *  *  *  *  *  * * | 0  0  2 0  0 0 0  0  {5} peppy base
 1  1  1 0  0 |  0  1  1  1  0  0  0  0  0  0  0 0 0 0 | *  *  *  * 24  *  *  *  *  *  * *  *  *  *  *  *  * * | 1  0  1 0  0 0 0  0  {3} thawro S-tropal
 1  1  1 0  0 |  0  1  1  0  1  0  0  0  0  0  0 0 0 0 | *  *  *  *  * 24  *  *  *  *  * *  *  *  *  *  *  * * | 0  1  1 0  0 0 0  0  {3} between neighbouring thawros
 0  1  2 2  0 |  0  0  0  2  0  0  0  0  2  0  0 1 0 0 | *  *  *  *  *  * 12  *  *  *  * *  *  *  *  *  *  * * | 1  0  0 1  0 0 0  0  {5} thawro N-tropal
 0  1  2 0  0 |  0  0  0  0  2  0  1  0  0  0  0 0 0 0 | *  *  *  *  *  *  * 12  *  *  * *  *  *  *  *  *  * * | 0  1  0 0  1 0 0  0  {3} between neighbouring thawros
 0  1  1 0  1 |  0  0  0  0  1  1  0  0  0  1  0 0 0 0 | *  *  *  *  *  *  *  * 24  *  * *  *  *  *  *  *  * * | 0  0  1 0  1 0 0  0  {3} peppy-squippy
 0  1  1 0  1 |  0  0  0  1  0  1  0  0  0  0  1 0 0 0 | *  *  *  *  *  *  *  *  * 24  * *  *  *  *  *  *  * * | 0  0  1 1  0 0 0  0  {3} peppy-mibdi
 0  1  0 0  2 |  0  0  0  0  0  2  0  0  0  0  0 0 0 1 | *  *  *  *  *  *  *  *  *  * 12 *  *  *  *  *  *  * * | 0  0  0 1  1 0 0  0  {3}
 0  0  4 0  0 |  0  0  0  0  0  0  2  2  0  0  0 0 0 0 | *  *  *  *  *  *  *  *  *  *  * 6  *  *  *  *  *  * * | 0  0  0 0  0 1 1  0  {4}
 0  0  2 1  0 |  0  0  0  0  0  0  1  0  2  0  0 0 0 0 | *  *  *  *  *  *  *  *  *  *  * * 12  *  *  *  *  * * | 1  0  0 0  0 1 0  0  {3} thawro N-tropal
 0  0  2 1  0 |  0  0  0  0  0  0  0  1  2  0  0 0 0 0 | *  *  *  *  *  *  *  *  *  *  * *  * 12  *  *  *  * * | 0  0  0 1  0 1 0  0  {3} between neighbouring thawros
 0  0  2 0  1 |  0  0  0  0  0  0  0  1  0  2  0 0 0 0 | *  *  *  *  *  *  *  *  *  *  * *  *  * 12  *  *  * * | 0  0  0 0  0 0 1  1  {3} at trip
 0  0  2 0  1 |  0  0  0  0  0  0  0  1  0  0  2 0 0 0 | *  *  *  *  *  *  *  *  *  *  * *  *  *  * 12  *  * * | 0  0  0 1  0 0 0  1  {3} at mibdi
 0  0  2 0  2 |  0  0  0  0  0  0  1  0  0  2  0 0 0 1 | *  *  *  *  *  *  *  *  *  *  * *  *  *  *  * 12  * * | 0  0  0 0  1 0 1  0  {4}
 0  0  1 0  2 |  0  0  0  0  0  0  0  0  0  1  1 0 1 0 | *  *  *  *  *  *  *  *  *  *  * *  *  *  *  *  * 24 * | 0  0  1 0  0 0 0  1  {3}
 0  0  0 3  0 |  0  0  0  0  0  0  0  0  0  0  0 3 0 0 | *  *  *  *  *  *  *  *  *  *  * *  *  *  *  *  *  * 2 | 2  0  0 0  0 0 0  0  {3} thawro top
--------------+----------------------------------------+-------------------------------------------------------+--------------------
 6  3  6 3  0 |  6  6  6  6  0  0  3  0  6  0  0 3 0 0 | 1  3  3  0  6  0  3  0  0  0  0 0  3  0  0  0  0  0 1 | 4  *  * *  * * *  *  thawro
 2  1  2 0  0 |  1  2  2  0  2  0  1  0  0  0  0 0 0 0 | 0  1  1  0  0  2  0  1  0  0  0 0  0  0  0  0  0  0 0 | * 12  * *  * * *  *  squippy-A (at thawro's 4s)
 1  2  1 0  2 |  0  2  1  1  1  2  0  0  0  1  1 0 1 0 | 0  0  0  1  1  1  0  0  1  1  0 0  0  0  0  0  0  1 0 | *  * 24 *  * * *  *  peppy
 0  2  4 2  2 |  0  0  0  4  0  4  0  2  4  0  4 1 0 1 | 0  0  0  0  0  0  2  0  0  4  2 0  0  2  0  2  0  0 0 | *  *  * 6  * * *  *  mibdi
 0  1  2 0  2 |  0  0  0  0  2  2  1  0  0  2  0 0 0 1 | 0  0  0  0  0  0  0  1  2  0  1 0  0  0  0  0  1  0 0 | *  *  * * 12 * *  *  squippy-B (at trip's 2-cup-lacing-4s)
 0  0  4 1  0 |  0  0  0  0  0  0  2  2  4  0  0 0 0 0 | 0  0  0  0  0  0  0  0  0  0  0 1  2  2  0  0  0  0 0 | *  *  * *  * 6 *  *  squippy-C (at trip's 2-cup-base-4)
 0  0  4 0  2 |  0  0  0  0  0  0  2  2  0  4  0 0 0 1 | 0  0  0  0  0  0  0  0  0  0  0 1  0  0  2  0  2  0 0 | *  *  * *  * * 6  *  trip
 0  0  2 0  2 |  0  0  0  0  0  0  0  1  0  2  2 0 1 0 | 0  0  0  0  0  0  0  0  0  0  0 0  0  0  1  1  0  2 0 | *  *  * *  * * * 12  tet
