Acronym srawv ditathi
Name small retrosphenoverted ditrigonary triakishecatonicosachoron
Circumradius sqrt[(15+3 sqrt(5))/2] = 3.294556
Colonel of regiment swavixady
Face vector 3600, 10800, 7680, 360
Confer
general polytopal classes:
Wythoffian polychora
External
links
hedrondude   polytopewiki   WikiChoron

As abstract polytope srawv ditathi is isomorphic to gwav ditathi, thereby replacing pentagrams by pentagons, and decagons by decagrams, respectively gid by id, tid by quit gissid, and sidditdid by gidditdid. – As such srawv ditathi is a lieutenant.


Incidence matrix according to Dynkin symbol

o3x5/2o3/2x5*b

. .   .   .    | 3600 |    4    2 |    2    2    4    1 |   1   2   2
---------------+------+-----------+---------------------+------------
. x   .   .    |    2 | 7200    * |    1    1    1    0 |   1   1   1
. .   .   x    |    2 |    * 3600 |    0    0    2    1 |   0   1   2
---------------+------+-----------+---------------------+------------
o3x   .   .    |    3 |    3    0 | 2400    *    *    * |   1   1   0
. x5/2o   .    |    5 |    5    0 |    * 1440    *    * |   1   0   1
. x   .   x5*b |   10 |    5    5 |    *    * 1440    * |   0   1   1
. .   o3/2x    |    3 |    0    3 |    *    *    * 1200 |   0   0   2
---------------+------+-----------+---------------------+------------
o3x5/2o   .       30 |   60    0 |   20   12    0    0 | 120   *   *
o3x   .   x5*b    60 |   60   30 |   20    0   12    0 |   * 120   *
. x5/2o3/2x5*b    60 |   60   60 |    0   12   12   20 |   *   * 120

o3x5/3o3x5*b

. .   . .    | 3600 |    4    2 |    2    2    4    1 |   1   2   2
-------------+------+-----------+---------------------+------------
. x   . .    |    2 | 7200    * |    1    1    1    0 |   1   1   1
. .   . x    |    2 |    * 3600 |    0    0    2    1 |   0   1   2
-------------+------+-----------+---------------------+------------
o3x   . .    |    3 |    3    0 | 2400    *    *    * |   1   1   0
. x5/3o .    |    5 |    5    0 |    * 1440    *    * |   1   0   1
. x   . x5*b |   10 |    5    5 |    *    * 1440    * |   0   1   1
. .   o3x    |    3 |    0    3 |    *    *    * 1200 |   0   0   2
-------------+------+-----------+---------------------+------------
o3x5/3o .       30 |   60    0 |   20   12    0    0 | 120   *   *
o3x   . x5*b    60 |   60   30 |   20    0   12    0 |   * 120   *
. x5/3o3x5*b    60 |   60   60 |    0   12   12   20 |   *   * 120

o3/2x5/2o3/2x5*b

.   .   .   .    | 3600 |    4    2 |    2    2    4    1 |   1   2   2
-----------------+------+-----------+---------------------+------------
.   x   .   .    |    2 | 7200    * |    1    1    1    0 |   1   1   1
.   .   .   x    |    2 |    * 3600 |    0    0    2    1 |   0   1   2
-----------------+------+-----------+---------------------+------------
o3/2x   .   .    |    3 |    3    0 | 2400    *    *    * |   1   1   0
.   x5/2o   .    |    5 |    5    0 |    * 1440    *    * |   1   0   1
.   x   .   x5*b |   10 |    5    5 |    *    * 1440    * |   0   1   1
.   .   o3/2x    |    3 |    0    3 |    *    *    * 1200 |   0   0   2
-----------------+------+-----------+---------------------+------------
o3/2x5/2o   .       30 |   60    0 |   20   12    0    0 | 120   *   *
o3/2x   .   x5*b    60 |   60   30 |   20    0   12    0 |   * 120   *
.   x5/2o3/2x5*b    60 |   60   60 |    0   12   12   20 |   *   * 120

o3/2x5/3o3x5*b

.   .   . .    | 3600 |    4    2 |    2    2    4    1 |   1   2   2
---------------+------+-----------+---------------------+------------
.   x   . .    |    2 | 7200    * |    1    1    1    0 |   1   1   1
.   .   . x    |    2 |    * 3600 |    0    0    2    1 |   0   1   2
---------------+------+-----------+---------------------+------------
o3/2x   . .    |    3 |    3    0 | 2400    *    *    * |   1   1   0
.   x5/3o .    |    5 |    5    0 |    * 1440    *    * |   1   0   1
.   x   . x5*b |   10 |    5    5 |    *    * 1440    * |   0   1   1
.   .   o3x    |    3 |    0    3 |    *    *    * 1200 |   0   0   2
---------------+------+-----------+---------------------+------------
o3/2x5/3o .       30 |   60    0 |   20   12    0    0 | 120   *   *
o3/2x   . x5*b    60 |   60   30 |   20    0   12    0 |   * 120   *
.   x5/3o3x5*b    60 |   60   60 |    0   12   12   20 |   *   * 120
