Acronym sraghi
Name small rhombated grand hecatonicosachoron
Circumradius sqrt[5+sqrt(5)] = 2.689994
Colonel of regiment (is itself locally convex – uniform polychoral members:
by cells: gid saddid srid stip tigid
rawvathi 12012000120
sraghi 12001207200
& others)
Face vector 3600, 10800, 8160, 960
Confer
general polytopal classes:
Wythoffian polychora
External
links
hedrondude   polytopewiki   WikiChoron

As abstract polytope sraghi is isomorphic to qragishi, thereby interchanging pentagrams and pentagons, resp. replacing stip by pip, srid by qrid, and gid by id.


Incidence matrix according to Dynkin symbol

x5o3x5/2o

. . .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
----------+------+-----------+--------------------+------------
x . .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
. . x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
----------+------+-----------+--------------------+------------
x5o .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x . x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
. o3x   . |    3 |    0    3 |   *    * 2400    * |   1   0   1
. . x5/2o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
----------+------+-----------+--------------------+------------
x5o3x   .    60 |   60   60 |  12   30   20    0 | 120   *   *
x . x5/2o    10 |    5   10 |   0    5    0    2 |   * 720   *
. o3x5/2o    30 |    0   60 |   0    0   20   12 |   *   * 120

x5o3x5/3o

. . .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
----------+------+-----------+--------------------+------------
x . .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
. . x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
----------+------+-----------+--------------------+------------
x5o .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x . x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
. o3x   . |    3 |    0    3 |   *    * 2400    * |   1   0   1
. . x5/3o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
----------+------+-----------+--------------------+------------
x5o3x   .    60 |   60   60 |  12   30   20    0 | 120   *   *
x . x5/3o    10 |    5   10 |   0    5    0    2 |   * 720   *
. o3x5/3o    30 |    0   60 |   0    0   20   12 |   *   * 120

x5/4o3/2x5/2o

.   .   .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
--------------+------+-----------+--------------------+------------
x   .   .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
.   .   x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
--------------+------+-----------+--------------------+------------
x5/4o   .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x   .   x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
.   o3/2x   . |    3 |    0    3 |   *    * 2400    * |   1   0   1
.   .   x5/2o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
--------------+------+-----------+--------------------+------------
x5/4o3/2x   .    60 |   60   60 |  12   30   20    0 | 120   *   *
x   .   x5/2o    10 |    5   10 |   0    5    0    2 |   * 720   *
.   o3/2x5/2o    30 |    0   60 |   0    0   20   12 |   *   * 120

x5/4o3/2x5/3o

.   .   .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
--------------+------+-----------+--------------------+------------
x   .   .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
.   .   x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
--------------+------+-----------+--------------------+------------
x5/4o   .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x   .   x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
.   o3/2x   . |    3 |    0    3 |   *    * 2400    * |   1   0   1
.   .   x5/3o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
--------------+------+-----------+--------------------+------------
x5/4o3/2x   .    60 |   60   60 |  12   30   20    0 | 120   *   *
x   .   x5/3o    10 |    5   10 |   0    5    0    2 |   * 720   *
.   o3/2x5/3o    30 |    0   60 |   0    0   20   12 |   *   * 120
