Acronym sirgashi
Name small rhombated grand stellated hecatonicosachoron
Circumradius sqrt[7-2 sqrt(5)] = 1.589926
General of army srahi
Colonel of regiment (is itself locally convex – uniform polychoral members:
by cells: did ided raded stip tiggy
grawv hidy 12012000120
sirgashi 12001207200
& others)
Face vector 3600, 10800, 7200, 960
Confer
general polytopal classes:
Wythoffian polychora
External
links
hedrondude   polytopewiki   WikiChoron

As abstract polytope sirgashi is isomorphic to sirghi, thereby interchanging pentagrams and pentagons, resp. replacing stip by pip.


Incidence matrix according to Dynkin symbol

x5/2o5x5/2o

.   . .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
------------+------+-----------+--------------------+------------
x   . .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
.   . x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
------------+------+-----------+--------------------+------------
x5/2o .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x   . x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
.   o5x   . |    5 |    0    5 |   *    * 1440    * |   1   0   1
.   . x5/2o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
------------+------+-----------+--------------------+------------
x5/2o5x   .    60 |   60   60 |  12   30   12    0 | 120   *   *
x   . x5/2o    10 |    5   10 |   0    5    0    2 |   * 720   *
.   o5x5/2o    30 |    0   60 |   0    0   12   12 |   *   * 120

x5/2o5x5/3o

.   . .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
------------+------+-----------+--------------------+------------
x   . .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
.   . x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
------------+------+-----------+--------------------+------------
x5/2o .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x   . x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
.   o5x   . |    5 |    0    5 |   *    * 1440    * |   1   0   1
.   . x5/3o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
------------+------+-----------+--------------------+------------
x5/2o5x   .    60 |   60   60 |  12   30   12    0 | 120   *   *
x   . x5/3o    10 |    5   10 |   0    5    0    2 |   * 720   *
.   o5x5/3o    30 |    0   60 |   0    0   12   12 |   *   * 120

x5/3o5/4x5/2o

.   .   .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
--------------+------+-----------+--------------------+------------
x   .   .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
.   .   x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
--------------+------+-----------+--------------------+------------
x5/3o   .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x   .   x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
.   o5/4x   . |    5 |    0    5 |   *    * 1440    * |   1   0   1
.   .   x5/2o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
--------------+------+-----------+--------------------+------------
x5/3o5/4x   .    60 |   60   60 |  12   30   12    0 | 120   *   *
x   .   x5/2o    10 |    5   10 |   0    5    0    2 |   * 720   *
.   o5/4x5/2o    30 |    0   60 |   0    0   12   12 |   *   * 120

x5/3o5/4x5/3o

.   .   .   . | 3600 |    2    4 |   1    4    2    2 |   2   2   1
--------------+------+-----------+--------------------+------------
x   .   .   . |    2 | 3600    * |   1    2    0    0 |   2   1   0
.   .   x   . |    2 |    * 7200 |   0    1    1    1 |   1   1   1
--------------+------+-----------+--------------------+------------
x5/3o   .   . |    5 |    5    0 | 720    *    *    * |   2   0   0
x   .   x   . |    4 |    2    2 |   * 3600    *    * |   1   1   0
.   o5/4x   . |    5 |    0    5 |   *    * 1440    * |   1   0   1
.   .   x5/3o |    5 |    0    5 |   *    *    * 1440 |   0   1   1
--------------+------+-----------+--------------------+------------
x5/3o5/4x   .    60 |   60   60 |  12   30   12    0 | 120   *   *
x   .   x5/3o    10 |    5   10 |   0    5    0    2 |   * 720   *
.   o5/4x5/3o    30 |    0   60 |   0    0   12   12 |   *   * 120
