Acronym quippirgashi
Name quasiprismatorhombated grand stellated hecatonicosachoron
Circumradius sqrt[13-5 sqrt(5)] = 1.348948
General of army 1/(3f+2)-f3x3o5x
Colonel of regiment (is itself locally convex – uniform polychoral members:
by cells: gaquatid ided quit sissid raded stiddip stip
giphidy 12012012000720
quippirgashi 00120120720720
& others)
Face vector 7200, 18000, 11520, 1680
Confer
general polytopal classes:
Wythoffian polychora
External
links
hedrondude   polytopewiki   WikiChoron

As abstract polytope quippirgashi is isomorphic to pirghi, thereby replacing the decagrams by decagons and interchanging the roles of pentagons and pentagrams, resp. replacing the quit sissid by tigid, the stiddip by dip, and the stip by pip.


Incidence matrix according to Dynkin symbol

x5/3x5o5/2x

.   . .   . | 7200 |    1    2    2 |    2    2    1    2    1 |   1   2   1   1
------------+------+----------------+--------------------------+----------------
x   . .   . |    2 | 3600    *    * |    2    2    0    0    0 |   1   2   1   0
.   x .   . |    2 |    * 7200    * |    1    0    1    1    0 |   1   1   0   1
.   . .   x |    2 |    *    * 7200 |    0    1    0    1    1 |   0   1   1   1
------------+------+----------------+--------------------------+----------------
x5/3x .   . |   10 |    5    5    0 | 1440    *    *    *    * |   1   1   0   0
x   . .   x |    4 |    2    0    2 |    * 3600    *    *    * |   0   1   1   0
.   x5o   . |    5 |    0    5    0 |    *    * 1440    *    * |   1   0   0   1
.   x .   x |    4 |    0    2    2 |    *    *    * 3600    * |   0   1   0   1
.   . o5/2x |    5 |    0    0    5 |    *    *    *    * 1440 |   0   0   1   1
------------+------+----------------+--------------------------+----------------
x5/3x5o   .    60 |   30   60    0 |   12    0   12    0    0 | 120   *   *   *
x5/3x .   x    20 |   10   10   10 |    2    5    0    5    0 |   * 720   *   *
x   . o5/2x    10 |    5    0   10 |    0    5    0    0    2 |   *   * 720   *
.   x5o5/2x    60 |    0   60   60 |    0    0   12   30   12 |   *   *   * 120

x5/3x5/4o5/3x

.   .   .   . | 7200 |    1    2    2 |    2    2    1    2    1 |   1   2   1   1
--------------+------+----------------+--------------------------+----------------
x   .   .   . |    2 | 3600    *    * |    2    2    0    0    0 |   1   2   1   0
.   x   .   . |    2 |    * 7200    * |    1    0    1    1    0 |   1   1   0   1
.   .   .   x |    2 |    *    * 7200 |    0    1    0    1    1 |   0   1   1   1
--------------+------+----------------+--------------------------+----------------
x5/3x   .   . |   10 |    5    5    0 | 1440    *    *    *    * |   1   1   0   0
x   .   .   x |    4 |    2    0    2 |    * 3600    *    *    * |   0   1   1   0
.   x5/4o   . |    5 |    0    5    0 |    *    * 1440    *    * |   1   0   0   1
.   x   .   x |    4 |    0    2    2 |    *    *    * 3600    * |   0   1   0   1
.   .   o5/3x |    5 |    0    0    5 |    *    *    *    * 1440 |   0   0   1   1
--------------+------+----------------+--------------------------+----------------
x5/3x5/4o   .    60 |   30   60    0 |   12    0   12    0    0 | 120   *   *   *
x5/3x   .   x    20 |   10   10   10 |    2    5    0    5    0 |   * 720   *   *
x   .   o5/3x    10 |    5    0   10 |    0    5    0    0    2 |   *   * 720   *
.   x5/4o5/3x    60 |    0   60   60 |    0    0   12   30   12 |   *   *   * 120
